Nguồn gốc:
Trung Quốc
Hàng hiệu:
Ruideer
Chứng nhận:
CE
Số mô hình:
336/4412/5518
Băng hình
Băng hình
Băng hình
Băng hình
1800 ℃ silicon carbide reaction sintering furnace
Sintering furnace is a batch-type of induction heating furnace, mainly used in the sintering of hard alloy and powder metallurgy industry producing size of silicon carbide powder, silicon carbide seal ceramic sintering, pressureless sintering of silicon carbide and titanium carbide powder and vanadium carbide powder and metal powder and composite metal powders.
Much easier and more convenient operation which names automatically furnace door open through touch screen operated.
Technology parameter:
| Model | RDE-3312-N | RDE-4412-N | RDE-5512-N |
RDE-5518-N |
| Working size | 300*300*1200 | 400*400*1200 | 500*500*1200 | 500*500*1800 |
| Max.capacity | 300 | 500 | 1200 | 1500 |
| Rated power(KW) | 250 | 250 | 350 | 480 |
|
Max.working temperature(℃) |
1800℃ | |||
|
Temperature niformity(℃) |
≤±5℃ | |||
| Rated voltage (V) | 380V | |||
| Vacuum ultimate (Pa) | 1pa(vacuum state) | |||
| Control type | Manual control/automatic control | |||
| Vacuum system | Rotary vane vacuum pump or slide valve and Roots vacuum pump | |||
| Working environment | Vacuum, Ar2 and such inert gas | |||
• Design standards
The equipment is designed in accordance with the pressure vessel requirements of the Quality and Technical Supervision Bureau, and is qualified after pressure testing and shipped. The electrical design and construction meet national standards.
• Installation pre-test and pre-acceptance
The equipment is fully assembled in our factory, including all pipelines, vacuum pipelines, process gas pipelines, cooling water pipelines, compressed air pipelines, etc. Pre-testing can be carried out after installation. At the customer site, pipelines other than the equipment are provided by the customer. The installation also includes the connection of all cables. At the customer site, the main cable connecting the power cabinet is provided by the customer. After installation, we conduct vacuum and positive pressure leakage tests on the entire equipment, as well as mechanical and electrical function tests.
• Disassembly and transportation
The equipment will be disassembled in several large parts, packed in a standardized manner, and loaded into the transport vehicle.
• Customer site installation and commissioning
The Redel after-sales engineer will lead the team to complete commissioning, product trial burning and other work within 20 working days. The customer needs to make appropriate preparations and provide the necessary tools, such as hoisting and lifting equipment. And provide installation personnel support (it is recommended to have 1 mechanical personnel and 1 electrical personnel).
• Final acceptance
After installation and commissioning, the equipment can be finally accepted in accordance with the requirements of the technical contract.
• Training
Our after-sales engineers will provide a systematic and complete on-site training, including operation, maintenance, troubleshooting, etc.
• Technical data delivery
To ensure safe operation and equipment maintenance, the following technical data will be provided to customers:
1. Equipment installation layout
2. User manual
3. Spare parts list
4. Electrical drawings
5. Component manual
FAQ
Q: Are you a factory or trading company?
A:We are China leading high-temperature vacuum furnace manufacturer with over 10 years’ experience.
Q: Do you have customization or OEM service??
A:Yes,we have powerful R&D team and high-tech equipment.So we can not only supply the regular model,but also the customizable furnace as the repuirment of our clients.
Q:What's your advantage?
A:
l Quick response to your enquiry
l High quality control
l Stable supply chain
l Timely delivery
l Excellent after-sales service
